lsr: ls but with io_uring
As an excercise in syscall golf, I wrote an implementation of ls(1) which uses my IO library, ourio to perform as much of the IO as possible. What I ended up with is something that is faster than any version or alternative to ls I tested, and also performs an order of magnitude fewer syscalls. I’m calling it lsr. Let’s start with the benchmarks, then we’ll see how we got there.
Time
Data gathered with hyperfine on a directory of n plain files.
| Program | n=10 | n=100 | n=1,000 | n=10,000 |
|---|---|---|---|---|
| lsr -al | 372.6 µs | 634.3 µs | 2.7 ms | 22.1 ms |
| ls -al | 1.4 ms | 1.7 ms | 4.7 ms | 38.0 ms |
| eza -al | 2.9 ms | 3.3 ms | 6.6 ms | 40.2 ms |
| lsd -al | 2.1 ms | 3.5 ms | 17.0 ms | 153.4 ms |
| uutils ls -al | 2.9 ms | 3.6 ms | 11.3 ms | 89.6 ms |
Syscalls
Data gathered with strace -c on a directory of n plain files. (Lower is better)
| Program | n=10 | n=100 | n=1,000 | n=10,000 |
|---|---|---|---|---|
| lsr -al | 20 | 28 | 105 | 848 |
| ls -al | 405 | 675 | 3,377 | 30,396 |
| eza -al | 319 | 411 | 1,320 | 10,364 |
| lsd -al | 508 | 1,408 | 10,423 | 100,512 |
| uutils ls -al | 445 | 986 | 6,397 | 10,005 |
How we got there
Let’s start with how lsr works. To list directory contents, we basically have 3 stages to the program:
- Parse args
- Gather data
- Print data
All of the IO involved happens in the second step. Wherever possible, lsr utilizes io_uring to pull in the data it needs. To get to that point, it means that we open the target directory with io_uring, if we need local time, user data, or group data, we open (and read) those files with io_uring. We do all stat calls via io_uring, and as needed we do the equivalent of an lstat via io_uring. In practice, this means that the number of syscalls we have should be drastically smaller than equivalent programs because we are able to batch the stat syscall. The results clearly show this…lsr has at least an order of magnitude fewer syscalls than it’s closest equivalent, being uutils ls.
We also use the zig stdlib StackFallbackAllocator. This let’s lsr allocate memory it needs up front, but fallback to a different allocator when it’s exhausted the fixed allocation. We allocate 1MB up front, which is more than enough for typical usage. This further reduces syscalls by reducing mmap usage.
As a result of working directly with io_uring, we also bypass several libc related pitfalls. Namely, we have no dynamic linking - ls has some considerable overhead in loading libc and related libraries…but it also has the benefit of having locale support. lsr does not boast such a feature. Despite being statically linked, lsr is still smaller than GNU ls: 138.7KB vs 79.3KB when built with ReleaseSmall.
Anomolies and Thoughts
I have no idea what lsd is doing. I haven’t read the source code, but from viewing it’s strace, it is calling clock_gettime around 5 times per file. Why? I don’t know. Maybe it’s doing internal timing of steps along the way?
Sorting ends up being a massive part of the workload. I suspect this is where uutils ls is getting slowed down, since it is doing pretty good on a syscall basis. lsr spends about 30% of it’s runtime sorting, the rest is the IO loop.
This ended up being a pretty fun project to write, and didn’t take too much time either. I am shocked at how much io_uring can be used to reduce syscalls…ls is a pretty basic example but you can only imagine how much of an effect this would have on something like a server.
Also - I’m using tangled.sh for this project. They have a really cool idea, and I want to see how the PR workflow is so…if you have any bugs or changes, please visit the repo. All you need is an atproto account + app password. I suspect more icons will be needed, feel free to make an issue for icon requests!
